Automatic Eddy Current Non-ferrous Metal Separator
Brief Introduction
1.Eddy current sorting machine is a metal separation equipment, also known as copper and aluminum sorting machine,non-ferrous metal eddy current sorting machine. The eddy current sorting machine has a good sorting effect on a variety of
non-magnetic metals. It can effectively separate non-metallic materials and non-ferrous metals automatically to recycle various non-ferrous metals with high efficiency and realize the mechanization and automation of the sorting process. It can reduce the production costs and increase the added value of products.
2.The eddy current separator is suitable for municipal solid waste, industrial waste, electronic waste, glass scrap, waste plastic doors and windows, urban wood waste, boiler bottom ash, various metal mixtures, shredded and sliced car waste, copper and aluminum and other non-ferrous metals recycling industry, environmental protection industry material sorting, etc.
3.The eddy current sorting machine is designed according to the principle that a conductor can generate an induced current in a high-frequency alternating magnetic field.
Technical Parameters
Model | Conveyor Width | Power | Capacity | Size | Weight |
YCX-4 | 400mm | 4kw | 1-2m³/h | 3000*880*1270mm | 780kg |
YCX-5 | 500mm | 4kw | 2-4 m³/h | 3000*980*1270mm | 980kg |
YCX-6 | 650mm | 4kw | 6 m³/h | 3000*1130*1270mm | 1100kg |
YC7-8 | 800mm | 7kw | 7.5 m³/h | 3500*1280*1370mm | 1200kg |
YCX-10 | 1000mm | 7kw | 9 m³/h | 3500*1480*1370mm | 1400kg |
YCX-12 | 1200mm | 7kw | 12 m³/h | 3500*1580*1370mm | 1500kg |
